L5 Reading Pen
Preschool-friendly OID 3.0 reading pen combining a large child-friendly tip with an external TF card slot for expandable libraries: SONIX 95303, five front buttons, Mini USB, earphone jack and 350 mAh rechargeable battery in a sleek glossy housing. Ideal for parent-child reading kits and growing preschool libraries.
The L5 Reading Pen pairs the child-friendly large pen tip with an expandable external TF card library — a combination most other models force buyers to choose between. Built
on the proven SONIX 95303 platform with OID 3.0, five front buttons and a sleek monochrome glossy housing, it is designed for preschool reading programs that start with one set of books and plan to add more. In the industry these devices are also widely called talking pens.Audio is loaded on a TF card that can be updated or expanded as your catalog grows, while the large tip and simple five-button layout stay forgiving for children aged roughly 3–6. A Mini USB port handles charging and data, and the 3.5 mm earphone jack supports quiet individual listening.
Key features
OID 3.0 recognition
Third-generation optical identification reads OID codes on board books, picture books, flashcards and posters quickly and reliably.
SONIX 95303 platform
The mature, mass-produced main-control chipset used across our best-selling entry models — stable supply chain and support.
Large preschool tip
The chunky SONIX large tip matches the grip and coordination of young children and is forgiving on thick board-book pages.
External TF card slot
The library lives on an external TF card, so new titles and expansions can be added after sale without changing the hardware.
Five front buttons
One round multi-function control cluster with power, track and volume markings keeps every playback function directly on the housing.
350 mAh battery
A built-in rechargeable lithium battery charges through the Mini USB port; an LED shows power and reading status at a glance.
Specifications
| Model / SKU | L5 |
|---|---|
| Main control chip | SONIX 95303 |
| OID version | OID 3.0 |
| Pen tip | SONIX large pen tip |
| Storage | One TF card slot supporting external TF card (card supplied per project) |
| Buttons | 5 front buttons |
| Charging / data port | Mini USB |
| Audio | Built-in speaker; 3.5 mm earphone jack |
| Indicator | LED status indicator |
| Battery | Built-in 350 mAh rechargeable lithium battery |
| Housing finish | Glossy injection-molded housing without spray coating |
| Typical content | Preschool OID book libraries, board books and picture-card series |
Need dimensions, weight, supported card capacities or lab test data for a tender file? These are configured per production batch — ask our sales engineer for the current L5 specification sheet.
Typical applications
Preschool libraries that expand
Start with a chunky large-tip pen for ages 3–6, then add new board-book titles and language packs on TF as the child progresses.
Parent-child reading kits
The monochrome adult-friendly styling fits premium parent-child gift sets sold through bookstores and maternity retail.
Headphone-based learning
With the 3.5 mm earphone jack, the L5 works for quiet individual listening in classrooms, waiting rooms and travel packs.
Multi-language starter packs
Keep one pen SKU in stock and configure different TF cards for English, Spanish, Arabic or bilingual programs by market.
Below is a short clip of the actual housing you’ll receive — useful to verify finishing, port placement and scan behaviour before you commit artwork.
Full Specifications & Procurement Information
For complete technical specifications, commercial terms, MOQ, lead time, packaging details and certifications, please download the L5 reading pen specification sheet below.
Frequently Asked Questions about the L5 Reading Pen
Answers to the most common buyer questions about the L5 OID reading pen — order process, customization, compatibility, warranty and after-sales support.
"How much audio content can the L5 store?"
The built-in 4 GB TF holds approximately 800–1,000 books at average MP3 bitrate (64 kbps). For larger libraries, use the L5's external USB mass-storage mode to drag-and-drop new books from a PC.
"Is the L5 the same as the K7?"
The L5 and K7 share the same SONIX 95303 platform and OID 3.0 codec, so they play identical books. The differences are: L5 has built-in storage (no card slot) and a gloss finish; K7 has external TF (you can swap cards to load new libraries instantly) and a matte finish.
"Can the L5 connect to a computer?"
Yes. Connect via the included micro-USB cable; the pen mounts as a USB mass-storage device. You can drag new OID-encoded book folders into the /books/ directory.
"What is the warranty on the L5?"
12-month manufacturer warranty. We stock replacement tips, batteries and PCBs for 36 months after your last order, ensuring long-term after-sales support.
"Can I get the L5 with a custom logo at low MOQ?"
Yes. Silk-screen logo printing starts at 1,000 pieces; full-colour pad printing starts at 3,000 pieces. Gift-box artwork is customised at any quantity.
"Is the L5 suitable for Arabic and Hebrew (right-to-left) books?"
Yes. OID 3.0 supports right-to-left scripts and we have shipped L5 pens with Arabic, Hebrew, Persian and Urdu firmware.
"How does the L5 compare to the Q8?"
The L5 is an audio-only reading pen (no extra cartridge slot). The Q8 adds a 2.4-inch colour TFT screen and video playback for higher-end multimedia books.
"What is the production lead time for an L5 bulk order?"
Standard production lead time is 30 days after deposit and artwork approval. For 5,000+ piece orders, allow an extra 7 days for quality inspection and pre-shipment sample approval.
How to use the L5 Reading Pen
- "Power on the L5". Press and hold the power button for 2 seconds. The blue LED lights up and the welcome voice plays.
- "Connect the L5 to a PC". Use the included micro-USB cable. The pen appears as a USB drive; copy new book folders into the /books/ directory.
- "Switch languages". Long-press the language button (third from top) to enter the language menu, then select with the up/down buttons.
- "Adjust reading speed". While a book is open, press the speed button (fourth from top) to cycle through 0.8x, 1.0x, 1.2x and 1.5x playback.
- "Charge the L5". Connect the micro-USB cable to any 5V/1A charger. Red LED = charging, green LED = full.
L5 Reading Pen — which fits your market?
Compare the L5 with the most common alternatives in our lineup, side by side.
| Model | Comparison angle | View product |
|---|---|---|
| K7 | "built-in vs external TF storage" | K7 |
| P2 | "mid-range audio-only vs entry-point audio-only" | P2 |
| Q8 | "audio-only vs multimedia with screen" | Q8 |
| B1 | "school vs preschool positioning" | B1 |
Procurement Information for the L5 Reading Pen
Standard terms for wholesale and OEM orders. Contact us for distributor pricing, custom quotes and shipping estimates.
| Minimum order quantity (MOQ) | 1000 pieces per SKU / colour |
|---|---|
| Sample lead time | 7 days |
| Bulk production lead time | 30 days after deposit and artwork approval |
| Sample fee | USD 50–80 per piece (refundable against bulk order) |
| Payment terms | T/T 30/70; L/C for orders over USD 50; 000 |
| Shipping ports | Shenzhen / Ningbo / Shanghai |
| Packaging options | gift box, retail blister, OEM neutral box |
| Trade terms | FOB / CIF / DDP available on request |
Request a quote for L5 Reading Pen · Wholesale program overview · Contact engineering
Certifications & Compliance for the L5 Reading Pen
All L5 reading pens are produced in our ISO 9001-certified factory and ship with the following test reports and compliance certificates. PDF copies available on request.
- CE — European Conformity — mandatory for sale in the European Economic Area
- FCC — Federal Communications Commission — required for electronic devices sold in the United States
- RoHS — Restriction of Hazardous Substances — limits lead, mercury, cadmium and other hazardous materials
- EN71 — European toy safety standard
- ASTM F963 — US toy safety standard — mechanical, flammability, chemical, electrical
- CPSIA — US Consumer Product Safety Improvement Act — children's products safety
- ISO 9001 — Quality management system certification — factory production control
See all factory certifications for full audit history and test lab reports.
OEM customization on the L5
The L5 uses existing production tooling, so customization starts at much lower volumes than a brand-new housing project:
- Custom colors — plastic compound matched to your Pantone plaque on the same glossy finish; the front panel can be color-coded separately.
- Logo and branding — pad printing on the housing and custom-printed gift boxes, manuals and inserts.
- TF content programs — starter cards preloaded in the factory, with a repeatable workflow for expansion titles; see how to prepare audio and OID print files.
- Accessory bundles — matched children's headphones, book sets and carry cases packed together as a finished retail kit.
- Family alternatives — need a matte finish and small tip for school-age series? See the K7; a fixed library with no card slot? Compare the B1.
See OEM vs ODM reading pen customization options for how color runs, logo work, packaging and new tooling are quoted.
Frequently asked questions
How is the L5 different from the B1 and B2?
All three use the SONIX 95303 chip, OID 3.0 and the large child-friendly tip. The B1 and B2 store audio on fixed built-in TF and use two or four buttons; the L5 adds a user-accessible external TF card slot for libraries that expand, with five buttons and Mini USB.
How is the L5 different from the K7?
Both support external TF cards. The K7 uses the smaller tip, four buttons and a matte housing aimed at school-age series; the L5 keeps the chunky large tip and glossy styling for preschool users.
Can parents add new books themselves?
New titles are distributed as updated or additional TF card content. Your program decides whether end users receive expansion cards, download packages, or simply get a new card with each book set — our team can help design the workflow.
Does it work with headphones?
Yes, the L5 includes a 3.5 mm earphone jack, so it supports standard wired children's headphones for quiet listening.
Does it support multiple languages?
The pen itself is language-neutral: it plays whatever audio is loaded on the card, so English, Spanish, Arabic, French, Russian and bilingual programs are all supported.
Plan a preschool library program on the L5
Send us your title roadmap, estimated order quantity and target market, and our engineering sales team will reply with a storage configuration, accessory options and project pricing.
